Ussivarustus Määrimine — Complete Oil Selection, Interval, and Contamination Guide

The three ways wrong lubricant destroys a correctly specified worm gear set — and the correct lubricant selection for every operating condition from food processing to marine offshore to sub-zero cold storage.

✗ EP additives reacting with bronze
✗ Wrong viscosity collapsing oil film
✗ Contamination circulating as abrasive

Why Worm Gear Lubrication Is Different from All Other Gear Types

A worm gear drive has a unique lubrication challenge: the sliding velocity at the mesh contact is predominantly along the tooth face rather than rolling across it. In a helical gear pair, the contact is primarily rolling. In a worm drive, the worm thread slides along the wheel tooth face across the full face width on every revolution — the same contact geometry as a lead screw sliding in a nut.

The consequence for lubricant selection: the Extreme Pressure (EP) additives that are formulated for the compressive loading of rolling contacts — sulfur, phosphorus, chlorine compounds — react with the copper and tin content of bronze and brass worm wheels to form metallic sulfide or chloride compounds that attack the tooth flank from within. An oil that is perfectly appropriate for the helical gear train on the same machine will destroy the bronze wheel of the worm drive operating alongside it within weeks.

uss ja ratas 2

EP additive contamination — the silent failure: When EP-additive oil is used with a bronze worm wheel, the copper sulfide attack produces a dark green-black discolouration of the oil and the wheel tooth surface. If EP oil has been used for any period, drain immediately, flush with clean non-EP oil, and inspect the wheel tooth flanks. The damage already done cannot be reversed — the gear set may be serviceable but life is shortened from first use of EP oil.


Viscosity Selection — The Central Reference Table

After eliminating EP-additive lubricants, viscosity grade is the most consequential selection parameter. The required viscosity depends on: worm shaft operating speed (which determines sliding velocity and lubrication regime), the gear housing operating temperature at equilibrium, and the module size (which determines the oil film thickness needed).

Märkus: Use housing equilibrium temperature during normal operation — not ambient. Housing temperature is typically 20–35°C above ambient for continuous-duty enclosed worm gear drives. An application in a 30°C factory runs at approximately 55–65°C housing temperature. If you do not know housing temperature, measure it with a surface thermometer after 2 hours of rated operation.

Housing Temp. Worm Speed (RPM) Module < M4 Module M4–M8 Module M8+ Oil Type
Below −10°C Any PAO ISO VG 100 PAO ISO VG 150 PAO ISO VG 220 Synthetic PAO only — mineral oil too viscous at low temp
−10°C to +20°C < 750 RPM Min. VG 320 or PAO 220 PAO ISO VG 220 PAO ISO VG 320 PAO preferred for wide temp range stability
+20°C to +45°C 750–1500 RPM Mineral or PAO VG 220 Mineral or PAO VG 320 Mineral or PAO VG 460 Mineral acceptable; PAO improves efficiency 3–7%
+20°C to +45°C > 1500 RPM Mineral or PAO VG 150 Mineral or PAO VG 220 Mineral or PAO VG 320 Higher speed → lower viscosity needed for film development
+45°C to +65°C Any Min. VG 320 or PAO 220 Mineral VG 460 or PAO 320 Mineral VG 680 or PAO 460 High temp requires higher viscosity to maintain film thickness
+65°C to +80°C Any PAO VG 220 recommended PAO VG 320 minimum PAO VG 460 Mineral oil at this temp has marginal film — PAO strongly preferred
Above +80°C Any PAO VG 320 — review thermal design PAO VG 460 — forced cooling may be needed PAO VG 680 — thermal redesign recommended Above 80°C sustained: lubrication risk zone regardless of oil grade

Lubricant Type Comparison — Mineral vs PAO vs Semi-Synthetic

Mineral Oil
ISO VG 220–680 · Non-EP
Viscosity index~85–100
Temp. stabilityGood to 70°C
Bronze compat.✓ if non-EP
Drain interval1,000–2,000 hrs
Cost (relative)1× (baseline)
Cold start (−10°C)Marginal
Standard choice · Temperature-stable applications
PAO Synthetic
ISO VG 100–460 · Non-EP
Viscosity index>150
Temp. stabilityExcellent to 120°C
Bronze compat.✓ excellent
Drain interval3,000–5,000 hrs
Cost (relative)3–4×
Cold start (−10°C)Suurepärane
Best performance · High temp · Marine · Food · VFD drives
Semi-Synthetic
ISO VG 220–460 · Non-EP blend
Viscosity index~110–130
Temp. stabilityGood to 80°C
Bronze compat.✓ verify additive pkg
Drain interval1,500–2,500 hrs
Cost (relative)1.5–2×
Cold start (−10°C)Good
Middle path · Cost-efficiency balance

Special Environment Lubricant Specifications

Environment Required Lubricant Type Viscosity Grade Key Requirement What to Avoid
Food processing — Zone 1/2 NSF H1 certified PAO VG 220–320 NSF H1 incidental food contact approval; no EP additives; bronze compatible NSF H2 (non-food contact only); any EP-additive oil
Marine / offshore Marine-grade PAO synthetic VG 220–460 per temp. VI >150 for thermal cycling; water separability; anti-rust properties Mineral oil with poor water separation; any EP-additive
Cold room (−18°C to −5°C) PAO synthetic, low pour point VG 100–150 Pour point below −40°C; adequate viscosity at operating temp for film formation Mineral ISO VG 460 (gels at low temp, causing overload)
High temperature (>80°C housing) High-temp PAO or ester-based VG 320–680 High flash point (>250°C); oxidation stability; low evaporation loss Standard mineral oil (oxidises rapidly above 70°C)
Pharmaceutical / medical NSF H1 PAO with ISO 10993-1 ref. VG 150–320 Biocompatibility documentation; no phenolic antioxidants; traceable batch Any oil without FDA/NSF compliance documentation
Plastic (PA66/POM) wheel Light PAO or dry grease VG 68–150 Chemically compatible with polyamide; low viscosity to reduce viscous drag Heavy mineral oil; EP additives attacking plastic additives

The Running-In Protocol — The Step Most Engineers Skip

The running-in period is the first 50–150 hours of operation after a new or replacement worm gear set is installed. During this period, the slightly rough as-manufactured surfaces conform to each other through controlled micro-asperity deformation. Incorrectly managed — by omitting the running-in oil change or loading the drive immediately to full torque — the running-in debris circulates as abrasive particles and initiates the accelerated wear cycle.

1
Fill with running-in oil charge
Before first start

Use the same oil type and grade specified for normal operation — do not use a ‘flushing oil’ or lighter oil for running-in. The running-in process requires the lubrication conditions of normal operation. Fill to the correct level mark (typically to the centre of the lowest bearing when the drive is stationary).

2
Start at 25–30% of rated torque
Hours 0–2

Run at rated speed but with reduced load for the first 2 hours. Monitor housing temperature every 20 minutes. If temperature rises above 80°C within the first 30 minutes, stop and investigate — the lubrication or cooling design may be inadequate.

3
Increase to 50% load
Hours 2–10

After 2 hours at 25–30%, increase to 50% rated torque for the next 8 hours. Temperature should stabilise within 30 minutes at this load level. If temperature is still rising after 30 minutes at 50% load, reduce load further and allow stabilisation before increasing again.

4
Drain running-in oil — critical step
At 10 hours (minimum) or 50 hours

After 10 hours of running-in operation, drain the oil completely. The running-in process has produced bronze wear particles — fine, suspended particles that remain in suspension indefinitely if not drained. Inspect the drained oil: a faint metallic sheen and light bronze-coloured metallic paste at the drain plug are normal. Green discolouration or large chunks indicate a problem — do not refill without investigating.

5
Refill with fresh production oil charge
After drain

Fill with fresh oil of the correct specification and grade to the correct level. This is the oil charge that will be used for the normal production service interval. The production oil change interval clock starts from this refill, not from the initial installation.

6
Increase to full load — gradual
Hours 10–60 post-drain

Over the next 40 hours, increase to 75% load, then 100% load. After 50 hours at full load, perform a second oil check: drain a small sample and check for unusual particle content, discolouration, or odour. If normal, resume the standard change interval from this point.


Change Interval Guide

Oil Change Intervals by Application and Lubricant Type
Standard Industrial · Mineral VG 320–460
1,000–2,000 hrs
Or 12 months, whichever comes first. Reduce by 30% if housing temperature regularly exceeds 65°C.
Standard Industrial · PAO Synthetic
3,000–4,000 hrs
Or 24 months. Calendar limit applies regardless of hours. Extend to 5,000 hrs with oil analysis at 3,000 hrs.
Food Processing · NSF H1 PAO
2,000 hrs or 12 months
More conservative calendar limit — food safety documentation requires demonstrable freshness. H1 certification on the fresh oil only.
Marine / Offshore · Marine PAO
2,000 hrs or 18 months
Reduce to 12 months if water ingress is possible. Test for water content at 1,000 hrs in humid marine atmosphere.
Cold Room (−18°C) · PAO VG 100–150
2,000 hrs or 12 months
Low temperature slows oil degradation but cold-temp cycling stresses seals. Annual change addresses seal condition as well as oil.
High Temp (>70°C housing) · PAO VG 460+
1,000 hrs or 6 months
High temp accelerates all oil degradation mechanisms. Oil analysis at 500 hrs to confirm adequate remaining life.

Contamination Management — The Overlooked Dimension

Contamination Sources

Where Contamination Enters

  • Shaft seal wear — worn lip seal allows ingress
  • Breather vent without filter — air pumping draws particles
  • Fill port without strainer — tool contamination at change
  • Casting sand from housing — not flushed at commissioning
  • Running-in debris — bronze particles from new gear mesh
  • External fluid ingress — wash-down, process fluids
Damage Path

How Contamination Causes Failure

  • Hard particles >25 µm act as three-body abrasives at the mesh
  • Particles scratch both shaft thread and wheel tooth flanks simultaneously
  • Scratched surfaces produce more particles — self-accelerating wear cycle
  • Water in oil creates electrolyte — accelerates corrosion at contact zone
  • Process fluid contamination may be acidic — attacks bronze alloy chemistry
Prevention Measures

Specify and Maintain These

  • Shaft seal inspection at every oil change — replace if lip worn or hardened
  • Filtered breather vent (10 µm filtration) on any drive in dusty environment
  • Oil fill port with magnetic strainer to capture ferrous particles
  • Running-in oil change at 50–100 hours — removes initial bronze particles
  • Housing flush on recommissioning after >3 months idle (corrosion products)
Detection Methods

How to Find Problems Early

  • Drain plug magnet — inspect at every change for metallic paste quantity
  • Oil colour check — green tint = EP reaction; black = overheating; milky = water
  • Oil analysis service — particle count, water content, viscosity, acid number
  • Drive temperature trend — rising temperature over months = increasing friction
  • Noise pattern — progressively louder = wear accumulation in progress

Korea Ever-Power tooted

Worm Gear Sets Designed for Correct Lubrication Practice

Legeerterasest uss- ja ussikäigukomplekt
Standard Duty · Mineral or PAO
Legeerterasest uss- ja ussikäigukomplekt
Standard industrial worm gear set supplied with a lubrication specification sheet that matches the oil type and viscosity grade to the documented operating conditions — housing temperature range, shaft speed, and module. The specification sheet is provided with the order confirmation. ZCuSn10Pb1 tin bronze wheel is specified for non-EP mineral or PAO oil — this is documented on the delivery note and the lubrication data sheet shipped with the gear set. The data sheet includes: recommended ISO VG grade at ambient temperature range, change interval at rated duty, first-change interval after running-in, and confirmation that EP-additive oil must not be used.

Vaata / taotle spetsifikatsiooni →

SS316 Stainless Worm Gear — Food & Pharma
Food Grade · NSF H1 Compatible
SS316 Stainless Worm Gear — Food & Pharma
All SS316 food-grade worm gear sets are delivered with NSF H1 lubricant compatibility documentation — confirming both that the gear materials are compatible with NSF H1 PAO oil chemistry and that the specification does not include any additive package that conflicts with H1 food safety requirements. The documentation states the acceptable NSF H1 oil viscosity range, the maximum operating temperature at which H1 compliance is maintained, and the recommended change interval for food production environments. For customers who have already selected a specific NSF H1 product by brand name, Korea Ever-Power can confirm compatibility before order placement.

Vaata / taotle spetsifikatsiooni →

Lubrication Specification Service
Application Support
Lubrication Specification Service
For applications with unusual operating conditions — wide temperature range, frequent VFD speed changes, combined food-grade and marine environment requirements, or any case where the standard viscosity table does not clearly indicate the correct specification — Korea Ever-Power provides a written lubrication specification as part of the order process. Provide the operating parameters (housing temperature range, shaft speed range, duty cycle, environment type, special requirements) and the application engineers confirm the lubricant type, viscosity grade, change interval, and any special running-in or commissioning requirements. This specification is part of the delivery documentation and can be shared with plant maintenance for the maintenance schedule.

Vaata / taotle spetsifikatsiooni →

Lubrication FAQ

Worm Gear Oil and Lubrication — Maintenance Questions Answered

How do I know if my current oil has EP additives that are incompatible with the bronze worm wheel?+

Check the oil technical data sheet or safety data sheet (SDS) for these indicators: (1) product is described as ‘EP gear oil,’ ‘extreme pressure gear lubricant,’ or ‘heavy-duty gear oil’ — these almost always contain EP additives; (2) the SDS lists sulfur compounds, organosulfur additives, or polysulfide compounds in the additive package; (3) the product is specifically recommended for helical, bevel, spur, or hypoid gears but does not mention worm gears or bronze compatibility. If any of these apply, do not use the oil in a bronze-wheeled worm drive. Acceptable oils will be labeled ‘worm gear oil,’ ‘suitable for bronze,’ ‘suitable for yellow metals,’ or ‘non-EP industrial gear oil.’

Can I mix two different non-EP oils when topping up, or must I use exactly the same brand and grade?+

Mixing non-EP oils from the same viscosity grade is generally acceptable in an emergency but not recommended as a normal practice. The additive packages of different oil brands may have compatibility issues — some antioxidants or anti-corrosion additives are incompatible with additives from different manufacturers, potentially forming deposits or reducing additive effectiveness when mixed. For a short-term top-up (adding <10% of total volume), the same viscosity grade from a different brand is acceptable. For a full oil change, always use a single product. Mixing mineral and PAO oils is not harmful chemically, but the drain interval should be set to the shorter of the two individual oils’ intervals.

My worm drive is making more noise in cold mornings but quiets down after running for 20 minutes. Is this a lubrication problem?+

Yes, almost certainly. At low ambient temperatures, mineral oil viscosity increases dramatically — ISO VG 460 mineral oil at 5°C may be 6–8× more viscous than at 40°C. The high-viscosity cold oil churning through the worm gear mesh creates viscous drag noise — typically a low-frequency rumble that decreases as the oil warms. If this is the only symptom and it resolves completely within 20 minutes, the gears themselves are not damaged. Switch to synthetic PAO ISO VG 220 — PAO’s high viscosity index means it remains more fluid at cold temperatures while maintaining adequate viscosity at operating temperature. If the noise does not completely resolve after warmup, investigate for abrasive wear or bearing damage alongside the lubricant issue.

I have a vertical shaft worm gear drive (worm shaft vertical). Does this change the lubrication requirements?+

Yes, significantly. In a horizontal worm shaft configuration, the oil level fills the lower part of the housing and the worm thread dips into the oil as it rotates, carrying oil to the mesh by splash lubrication. In a vertical shaft configuration, gravity drains oil away from the mesh zone, and splash lubrication is less effective or completely absent depending on orientation. For vertical worm shaft configurations, the oil level must be carefully set to ensure the worm thread passes through oil at the lowest point of its rotation — this requires a higher fill level than horizontal orientation. For upward-driving vertical worm configurations, forced lubrication (an oil pump circuit) may be required. Confirm the housing fill level specification with Korea Ever-Power at ordering for any non-standard mounting orientation.

What is the correct oil level in a worm gear housing?+

The standard oil level for a horizontal worm shaft configuration is the centre of the worm wheel pitch circle — the oil surface should be approximately level with the horizontal centre plane of the worm wheel when the drive is stationary. Overfilling beyond the centre of the worm wheel increases churning losses, raises housing temperature, and accelerates oil degradation — it does not improve lubrication and may worsen it by increasing viscous drag. Underfilling below the worm wheel centre means the mesh receives inadequate lubrication, particularly during starting and at low speeds. Check the oil level only when the drive has been stationary for at least 15 minutes — the oil level when running will be different from the settled level due to churning and film distribution.

Can I use grease instead of oil for a worm gear drive? Some small enclosed drives seem to use grease.+

Grease is used in some small, low-power worm gear applications — typically Module M2 and below, at low sliding velocities, and in sealed-for-life designs where oil changes are impractical. The grease must be formulated for worm gears: non-EP, non-sulfurised, bronze-compatible lithium or polyurea base grease. Grease lubrication is inherently less effective than oil immersion at removing heat from the mesh. For continuous-duty drives above approximately 0.5 kW, and for all drives where the housing temperature exceeds 50°C, oil immersion is strongly preferred over grease. Do not substitute standard multi-purpose grease (which typically contains EP additives and may contain molybdenum disulfide) for oil in a worm drive — the chemistry is incompatible with bronze.

My maintenance schedule calls for annual oil changes but the drive only runs 400 hours per year. Should I still change annually?+

Yes. The calendar interval (12 months) applies regardless of operating hours. Lubricant degradation occurs both through operating stress (heat, shear, oxidation from operation) and through calendar aging (oxidation from atmospheric exposure, additive settling, micro-contamination through seals during temperature cycling). A drive that only runs 400 hours per year still undergoes 8,760 hours of atmospheric exposure in 12 months. Annual oil changes remove the products of this calendar aging regardless of operating hours and allow inspection of the drained oil for any contamination that occurred during storage or infrequent operation.

What is the correct procedure if I have accidentally used EP-additive oil in a bronze-wheel worm drive?+

Act immediately. Procedure: (1) Stop the drive at the earliest safe opportunity; (2) Drain the EP-contaminated oil completely; (3) Fill with clean non-EP oil of the correct grade for the flush — use a lower viscosity grade (e.g., VG 100 PAO); (4) Run at 20% load for 30 minutes to circulate the flush oil and dissolve remaining EP-contaminated oil from housing surfaces; (5) Drain the flush oil; (6) Inspect the drained flush oil — if heavily green-discoloured, the EP attack was significant and the wheel flank damage warrants visual inspection; (7) Fill with correct production oil and restart at reduced load for 2 hours before returning to full load.

Get the Correct Lubrication Specification for Your Drive

Provide housing temperature range, shaft speed, module, environment type (food/marine/standard), and duty cycle. Korea Ever-Power returns a written lubrication specification — oil type, viscosity grade, change interval, and running-in protocol — with your order confirmation.
